small class · Diesel / LPG
AIS 09 Cyclone
Compact entry-class incinerator, top-loading lid for fast access.
Capacity
110 kg
243 lbs
Burn rate
50
kg / hour
Fuel
Diesel / LPG
—
AIS 09 Cyclone Information
What it does, and who it's for.
Be assured of a quality product and a quality service with AIS. Every Cyclone ships with a 3-year warranty as standard.
- Suited for smaller sites the AIS 09 is ideal for those looking for a regular, effective, and bio-secure animal-by-product incineration
- The AIS 09 Cyclone can deal with the disposal of animal-by-products generated across the agricultural sector including Poultry, Lambs, Game Farms, Estates, Butchers and Farm shops, Dog & Cat shelters.
- Burns up to *50kgs/111 lbs per hour.
- Load capacity of up to 110kg / 243 lbs.
- Loading is easy with full access to the main chamber via a Top Loading counterbalance lid.
- PLC timer controls with automatic burner shut off function and fast ignition burners. One temperature-controlled burner in the main chamber and one in the secondary chamber.
- Can be loaded whilst in operation maximizing the inherent thermal efficiency of our trusted monolithic concrete lining, keeping running costs low.
- Optional Extra features include Grate Bars / USB Data Logger / Ash Door / Stack Extensions / Ash Rake / Simple Heat Exchange system / Control Panel screen size increase / Service Kits.
At a glance
Engineered for the daily duty cycle.
The AIS 09 Cyclone is hand-built in the UK or U.S. with a monolithic concrete refractory lining, temperature-controlled burners, and a PLC control system.
- Capacity
- 110 kg / 243 lbs
- Burn rate (approx.)
- 50 kg/hr
- Fuel
- Diesel / LPG
- Refractory
- Monolithic concrete lining
- Lid
- Counterbalance / Top-loading
- Controls
- PLC with auto burner shut-off
- Warranty
- 3 years standard
- Build
- Hand-built UK & US
Highlights
- Top-loading counterbalance lid
- Twin temperature-controlled burners
- PLC timer with auto burner shut-off
Optional extras
Grate BarsUSB Data LoggerAsh DoorStack ExtensionsAsh RakeHeat ExchangeLarger Control PanelService Kits
Full specification
AIS 09 Cyclone — dimensions & performance
| Specification | Metric | Imperial |
|---|---|---|
| Burn Rate | 50 Up to kg/hr | 111 Up to Ibs/hr |
| Front / Top Load | Top | Top |
| Operational Dimensions Static (LxWxH) | 1.4 x 1.4 x 3.2 m | 4’ 7’’ x 4’ 7’’ x 10’ 8’’ feet/inch |
| External Height Static | 3240 mm inc. Stack | 10’ 8’’ feet/inch inc. Stack |
| External Height Static | 2300 mm ex. Stack | 7’ 7’’ feet/inch ex. Stack |
| Weight Static | 0.9 Tonne estimated | 1985 Ibs estimated |
| Load Height from Ground (floor to bottom edge) | 825 mm | 2' 7" feet/inch |
| Fuel Consumption Diesel | 4 – 7 LPH est during main burn | 1.1 – 1.7 GPH est during main burn |
| Fuel Consumption LPG | 5- 10 LPH est during main burn | 0.7 – 2.6 |
| Fuel Consumption Nat Gas | 4- 7 m³/h est during main burn | 152 – 232 ft³/h est during main burn |
| Grate Bars | Optional | Optional |
| Load Door Opening (Width x Height/Depth) | 630 x 480 mm area | 2’ 1’’ x 1’ 7’’ ft/inch area |
| Chamber Size (LxWxH) | 0.8 x 0.6 x 0.6 m | 2’ 6’’ x 2’ 1’’ x 2’ 1’’ ft/inch |
| Chamber Actual Volume | 0.27 m³ | 10 ft³ |
| Chamber Load Volume | 0.19 m³ | 7 ft³ |
| Chamber Load Capacity | 110 kg | 243 Ibs |
| Std Stack Diameter | 8’’ inch/mm 2D Size | 8’’ inch/mm 2D Size |
| No. Main Burners | 1 | 1 |
| No. Secondary Burners | 1 | 1 |
| Burner Output | 95 kW heat | 324,153 Btu heat |
| Electric Consumption | 0.2 kW electricity | 0.2 kW electricity |
* Burn rates, fuel consumption, weights and chamber capacities are estimates and depend on load type, moisture content, and operating conditions. Contact us for site-specific guidance.
